The Earth-Rite TELLUS monitors static earth connections for a wide range of filling, blending and mixing applications.
The flexible and lightweight indicator station is easy to install, and can be mounted in a variety of locations within the hazardous area, with the power supply mounted in the local ‘non-hazardous’ area.
If the TELLUS detects an abnormally high resistance in the static dissipation circuit it activates a set of output contacts to halt the process or engage alarm systems.
The equipment at risk of charge accumulation is earthed by simply connecting the ATEX/FM approved stainless steel earthing clamp, whereby the TELLUS immediately begins monitoring the connection to the equipment. Benefits:
- Continuously monitors clamp connection to equipment with a monitoring threshold of 10 ohms or less.
- Bright green flashing LED provides positive indication to personnel.
- Ensures resistance to earth is < 10 Ohms before process may begin
Certification:
ATEX / FM Ingress Protection:
IP 65 / NEMA 4X Power Supply:
110/120V or 220/240V AC, 50-60 Hz
